8-channel Serial Server - Industrial-grade RS232/485 Device Networking Server - NCOM580 - IPCSUN
Product Introduction
Solve the connection limitations and management needs of traditional serial devices in the modern network environment, and realize the remote access, centralized management and integration of devices with other systems. "Networking" traditional serial devices solves the pain points such as physical distance, system integration, centralized management and remote operation and maintenance, and is a key bridge connecting "traditional devices" with "modern networks" in scenarios such as industrial automation, smart parks and Internet of Things upgrades.
Technical Parameters
| Ethernet Interface | |
| Quantity | |
| Speed | 10/100M |
| Electromagnetic Isolation Protection | 2KV |
| Network Settings | |
| IP Assignment Policy | STATIC、AUTO/DHCP |
| Local IP Address | |
| Subnet Mask of the Device | |
| Local Gateway | |
| Serial Port | |
| Quantity | |
| Type | RS232/485 |
| Interface Form | Industrial wiring terminal |
| EMC | 500W Lightning Surge |
| Overcurrent Protection | RS485：30V/100mA |
| Serial Port Settings | |
| Baud rate | 1200、2400、4800、9600、19200、38400、57600、115200bps |
| Data Length | 7、8 |
| Stop Bit | 1、2 |
| Parity | Odd (Odd parity), Even (Even parity), None (No parity) |
| Operating Mode | TCP Server、TCP Client、UDP、UDP Server |
| Data Conversion Mode | DTU、ModbusRTU、ModbusASCII |
| Power Characteristics | |
| Interface Form | Industrial wiring terminal / DC round plug power interface |
| Input Voltage | DC9-30V |
| Power | ≦1.4W |
| EMC | 500W Lightning Surge |
| Overcurrent Protection | Support |
| Overvoltage Protection | Support |
| Reverse connection protection | Support |
| Operating Environment | |
| Operating Temperature | -40℃～85℃ |
| Storage Temperature | -40℃～85℃ |
| Relative Humidity | ≦95%RH |
| Mechanical Characteristics | |
| Housing | Metal |
| IP rating | IP30 |
| Dimensions | Length * Width * Height (mm) 192×118×30.5 (without mounting plate), 217×118×30.5 (with mounting plate) |
| Experimental Standards | |
| Electrostatic Discharge Immunity (ESD) | GB/T 17626.2 (IEC 61000-4-2) (Contact discharge ±8kV) |
| Electrical Fast Transient/Burst (EFT) | GB/T 17626.4-2018 (Network port: ±2kV; Power port: ±4kV; Signal port: ±4kV) |
| Low/High Temperature Test | GB/T 2423.1, 2 (High temperature 85°C, Low temperature -40°C) |
| Certification | |
| FCC | 47 CRF FCC Part 15，Subpart B ANSI C63.4-2014 |
| RoHS | (EU)2015/863-PASS |
Product Advantages
◆ Supports registration function for convenient connection to cloud platforms
Industry Applications
