Industrial Intelligent Gateway - IoT Data Acquisition Gateway - Sensor/Instrument Data Acquisition Gateway - MBE142
PRODUCT INTRODUCTION
MBE142 is an industrial multi-functional integrated processor developed by our company. It provides 2-way Ethernet, 16-way composite serial port, 1-way can, built-in 4-way relay, 6-way Di acquisition, supports dual IP, provides dual power supply, has powerful and flexible module functions, and has the functions of composite serial port server, edge computing data acquisition gateway, remote i/o, and can to Ethernet device
SPECIFICATION PARAMETERS
| Parameter Category | Parameter Item | Parameter Value |
| Channel Parameters | Ethernet port | 2 ports, 10/100M auto-adaptive |
| Relay Channel (DO) | 4-channel normally open/closed relay | |
| Serial Port Channel | 16-channel RS232/485 composite serial port | |
| Acquisition Channel (DI) | 6 channels (active/passive) | |
| CAN Channel | 1 CAN channel | |
| Power Input | AC 85-305V(1-2路) | |
| Power Output | 2路 DC 12V/0.2A | |
| Serial Port Parameters | Baud rate | 1200-115200bps |
| Data Bits | 7 or 8 bits | |
| Stop Bit | 1 bit and 2 bits | |
| Parity Check Method | Odd parity, even parity, no parity | |
| Acquisition Channel (DI) Input Parameters | Active Level Signal | High level is "1": +5.0V~30V |
| Low level for "0": 0~+3.0V | ||
| Passive switch signal | Open circuit state is "0 | |
| Closed state is "1 | ||
| Relay Channel (DO) Parameters | Rating | 10A 277VAC/12A 125VAC |
| Closing Type | Normally Open / Normally Closed | |
| CAN Channel Parameters | Communication Rate | 5-1000K |
| Protection Parameters | Ethernet port | 2KV Electromagnetic Isolation Protection |
| Serial Port/DI/DO | 500W lightning surge protection | |
| CAN port | 1KV electromagnetic isolation protection, 2KV lightning surge protection | |
| Power Parameters | AC Voltage | AC 85-305V |
| DC Voltage | DC 100-430V | |
| Power | ＜6.5W | |
| Power Protection Parameters | Electrical Fast Transient Immunity | 4KV |
| Surge Immunity | 4KV | |
| Isolation Voltage | 4KV | |
| Conducted Disturbance Immunity | 10Vr.m.s | |
| Environmental Requirements | Operating Temperature | -40℃~80℃ |
| Operating Humidity | ≤95%RH |
PRODUCT ADVANTAGES
The hardware of this series of equipment is completely designed in accordance with industrial standards, and the communication interface is protected against lightning surge. The power supply has wide working voltage range, anti connection and lightning protection, and can work stably in harsh electrical environment for a long time.
(1) Industrial grade 32-bit ARM9 processor with 300MHz main frequency, 64M memory and flash256m are adopted, with strong real-time processing ability
(2) All communication interfaces shall be protected against lightning and surge
(3) 10/100m adaptive Ethernet interface, supporting dynamic IP and static IP
(4) It also supports Ethernet and serial port signal communication, and supports standard Modbus Protocol
(5) I/o acquisition supports wet and dry contacts, and can collect switch signals as well as level signals
(6) Output supports initial state locking, output locking and security state setting
(7) It supports 8-way rs232/485 and can be used as a serial port server. It also has the function of Modbus gateway
(8) It supports 4-way power output and can supply power to multiple modules at the same time, making the construction site more convenient
(9) Support a variety of parameter configuration methods such as web pages and PC software, and the configuration parameters are convenient and flexible
(10) It is a multi interface, multi signal and intelligent integrated gateway
(11) Reliable design of multiple software and hardware to ensure safe operation of equipment
(12) It can be directly controlled in the cloud and can submit customized content
(13) With reset key, it can restore to the factory setting in case of chaotic system parameter configuration
(14) High grade metal shell, exquisite and beautiful, and can effectively protect the stable operation of the product
(15) Support registration function to facilitate docking with cloud platform
INDUSTRY APPLICATION
